Key Features
Specification
Model |
GD11 1K/1KL |
GD11 2K/2KL |
GD11 3K/3KL |
GD11 6K/6KL |
GD11 8K/8KL |
||
Capacity |
1KVA/0.8KW |
2KVA/1.6KW |
3KVA/2.4KW |
6KVA/4.8KW |
8KVA/6.4KW |
||
HOST MACHINE | |||||||
Transformer |
Output Isolation Transformer |
||||||
Overall Efficiency (AC - AC) |
>85% |
||||||
Noise (In 2 meters) |
<50dB |
||||||
Working Temperature |
-10 to 40℃ |
||||||
Storage Temperature |
-25 to 60℃ (Without Battery) |
||||||
Humidity |
<95% Non-Condensing |
||||||
Parallel Redundancy |
Available |
||||||
DC Start |
Available |
||||||
Display |
LCD Display: Multi-Language with all kinds of messages. Input Output Status, ECO Mode Settings, Inverter Temperature, Transformer Status, Operation Time, Serial Number, Model, Structure, History Logs, Battery Test. |
||||||
|
|
||||||
Protection level |
IP 20 |
||||||
Elevation |
<1000M, Without Derated |
||||||
INPUT | |||||||
Input Voltage |
200/220/230/240Vac Single Phase |
||||||
Input Voltage Range |
160-280Vac |
||||||
Input Frequency Range |
50 ± 5% Hz |
||||||
Soft-Start |
> 20 Seconds |
||||||
OUTPUT | |||||||
Output Voltage |
200/220/230/240Vac |
||||||
Output PF |
0.8 |
||||||
Output Voltage Regulation |
220 Vac ± 1% (Static Full Load), 220 Vac ± 2% (50-0% Sudden Change) |
||||||
Output Frequency |
50Hz±0.1% (BAT Mode) |
||||||
Distortion |
< 1%(Linear Full Load) , < 3%（Non-Linear Full Load） |
||||||
Frequency Tracking Range |
46-54Hz |
||||||
Output Waveform |
Pure Sine Wave |
||||||
Overload capability |
> 125%: More than 10 Min； > 150%: More than 1 min |
||||||
Crest Ratio |
3∶1 |
||||||
BYPASS | |||||||
Static Bypass Transfer Time |
0 ms |
||||||
Static Bypass Range |
220Vac (-15~+15%) |
||||||
Frequency Range |
±1Hz, ±2Hz, ±3Hz Adjustable |
||||||
Bypass -> INV Transfer Time |
2ms |
||||||
Frequency Tracking Speed |
0.5~2hz/s |
||||||
Manual Maintenance Bypass |
None |
Available |
|||||
ALARM | |||||||
Alarm |
Utility Power Fault, BAT Voltage Low, Overload,UPS Fault |
||||||
Mute |
Auto |
||||||
BATTERY | |||||||
DC voltage |
72VDC |
72VDC |
96VDC |
96VDC/192VDC |
192VDC |
||
Std.Model Charging Current |
Standard backup model: 1A; External backup model: 5A (Optional to 10A) |
||||||
COMMUNICATION | |||||||
Communication Port |
RS232 (Standard)；SNMP/RS485/ Dry Contact （Optional Accessory） |
||||||
PHYSICAL | |||||||
Std.Dimension WxDxH (mm) |
220 x 510 x 395 |
220 x 610 x 635 |
None |
||||
Ext. Dimension WxDxH (mm) |
220 x 510 x 395 |
220 x 610 x 475 |
220 x 610 x 715 |
||||
RM Size mm (W x D x H) |
430 x 540 x 178/4U |
430 x 540 x 264/6U |
430 x 600 x 352/8U |
||||
Std. Net Weight Kg |
37.5 |
38.5 |
49 |
84 |
None |
||
Ext. Net Weight Kg |
22.5 |
23.5 |
29 |
44 |
61 |
||
RM Size mm (W x D x H) |
None |
23 |
29 |
43 |
None |
||
